Product characteristics

Electrical design: PNP
Output function: Normally open
Sensing range [mm]: 5
Housing: threaded type
Dimensions [mm]: M18 x 1 / L = 70

Application

Special feature: Gold-plated contacts; Full-metal housing
Pressure rating

Electrical data

Operating voltage [V]: 10…36 DC
Current consumption [mA]: < 20
Protection class: III
Reverse polarity protection: Yes

Outputs

Electrical design: PNP
Output function normally: Open
Max. voltage drop switching output DC [V]: 2.5
Permanent current rating of switching output DC [mA]: 100
Switching frequency DC [Hz]: 100
Short-circuit protection: yes
Type of short-circuit protection: Pulsed
Overload protection: Yes

Detection zone

Sensing range [mm]: 5
Operating distance [mm]: 0…4.05

Tests / approvals

II 3G Ex nA IIC T6 Gc X

II 3D Ex tc IIIC T85°C Dc IP67 X

EN 61000-4-2 ESD 4 kV CD / 8 kV AD
EN 61000-4-3 HF radiated 10 V/m
EN 61000-4-4 Burst 2 kV
EN 61000-4-6 HF conducted 10 V
EN 55011 emission class B
