S70 VALVE 1/4” 5/3 simple sol. OC METALWORK 7020022200
€170.62 + IVA
P/N: 7020022200
3 in stock (can be backordered)
70 series valve electro-pneumatic couplings 1/4” 5/3 monostable with spring mechanical open centres.
TECHNICAL SHEET
| Valves – | |
| Flow-rate | 1,100.00 l/min |
| Flow-rate at 6.3 bar DP 1 bar (Nl/min) | 1100 |
| Functional denomination | valves |
| Max input pressure N | 10.00 bar |
| Max temperature (°C) | 60 |
| Min Input Pressur | 2.50 bar |
| Min temperature (°C) | -10 |
| Product’s series | Valve 70 series |
| Protection degree | IP 65 |
| Push-in fitting for pipe (Ø) | 10 |
| Thread type | Cylindrical gas |
| Type | Electro-pneumatic |
| Voltage | 12VDC – 24VDC – 24VAC – 110VAC – 220VAC |
| Way scheme | 5/3 |
https://media.metalwork.it/browse/catalogue-eng#page/821
| Weight | 0.265206 kg |
|---|
Brand
METAL WORK
METALWORK
