S70 VALVE elpn 1/8” 5/3 single sol.CP METAL WORK 7010022300
€148.50 + IVA
P/N: 7010022300
3 in stock (can be backordered)
70 series valve electro-pneumatic couplings 1/8” 5/3 monostable with spring mechanical open under pressure
TECHNICAL SHEET
| Valves – | |
| Flow-rate | 550.00 l/min |
| Flow-rate at 6.3 bar DP 1 bar (Nl/min) | 550 |
| Functional denomination | valves |
| Max input pressure N | 10.00 bar |
| Max temperature (°C) | 60 |
| Min Input Pressur | 2.50 bar |
| Min temperature (°C) | -10 |
| Product’s series | Valve 70 series |
| Protection degree | IP 65 |
| Push-in fitting for pipe (Ø) | 1/8″ |
| Thread type | Cylindrical gas |
| Type | Electro-pneumatic |
| Voltage | 12VDC – 24VDC – 24VAC – 110VAC – 220VAC |
| Way scheme | 5/3 |
https://media.metalwork.it/browse/catalogue-eng#page/821
| Weight | 0.187111 kg |
|---|
Brand
METAL WORK
METALWORK
